Features:

• SC / APC GPON optical interface
• Supports two POTS ports with RJ-11 connector
• Supports 4 10/100/1000Base-T Ethernet ports with RJ-45 connector
• Supports half / full duplex and flow control, auto negotiation or manual configuration
• Supports MDI / MDIX auto-sensing
• 1 CATV interface
• 12 V Power Input Interface. +12 V DC (via external AC/DC adapter: 90-264 V, 50/60 Hz AC input, 12 V DC output)
• 1 USB host interface. Complies with USB 2.0 specifications

GPON Features:

• ITU-T G.984 and ITU-T G.988 compatible
• Flexible mapping between GEM port and T-CONT

Ethernet Features:

• MAC address learning
• MAC address aging
• MAC address learning enable / disable
• MAC address learning limit
• MAC address binding to a user port. Only controls the input side of the port
• Anti-MAC transferring (spoofing)
• Forbids the MAC addresses learned from a user port to be transferred to other user port before aging
• Forbids the MAC addresses learned from an uplink port to be transferred to the user port
• MAC filtering
• Both the source and destination MAC addresses support the blacklist and the white list function


WiFi Features:

• The WiFi function provides an easy, convenient, flexible, and cost-efficient method for users to access the Internet via a wireless LAN network
• Supports 2.4 GHz (2x2 MIMO), IEEE802.11b / g / n compliant
• Supports 5 GHz (4x4 MIMO), IEEE802.11a / n / ac compliant
• Auto and manual channel selection
• Auto and manual rate control
• Transmission power control
• Four SSIDs per frequency band
• Maximum 32 users per frequency band
• SSID broadcast enabling / disabling
• Access control based on MAC address
• WPA-PSK, WPA2-PSK, and WPA-PSK + WPA2-PSK security authentication
• WPS
• WMM
• Beamforming

USB Features:

• One USB 2.0 host port
• Supports file storage and sharing
• Supports print sharing
• Supports user configuration file fast recovery
• Supports USB LTE dongle backup in case of primary Internet connection failure


CATV Features:

• Standard F5-Type connector
• Analog RF video over dedicated 1550 nm wavelength
• RF output level of +17 dBmV
• RF Passband: 46 MHz - 1 GHz
• Switched on / off by remote control
• RF Output level AGC Adjustment
• Receiving sensitivity: -8 to 2 dBm
