Features
Indicate the signal directions and power in fiber;
Indicate the signal presence or absence(Live or dark fiber);
Efficiently identifies the traffic direction and frequency tone (270Hz, 1KHz, 2KHz) with audible warning;
Displays the relative core power ;
Easy-to-replace adaptors;
Lower power indication閿?/span>
Build in VFL function.
Specifications
Type | JW3306D |
Identified Wavelength Range | 750-1700 nm |
Insertion Loss | 1.0dB |
Fiber Type | 閿?/span> 3mm Fiber |
Identified Signal Type | 270Hz/1KHz/2KHz |
Display Type | LED |
Detector Type | 1mm InGaAs |
Minimum detection power | -35dBm(1550nm) |
-30dBm(1310nm) | |
Center Wavelength | 650nm |
Output Power | 10mW |
Alkaline Battery | 2*AA |
Battery Life | 閿?/span> 60H |
Operating Temperature | -10~+50閳?/span> |
Storage Temperature | -20~+60閳?/span> |
Dimension | 25.5*8*5.5cm |
Weight | 0.3kg |
