- Provides 1~4 output wavelengths which can be optional according to customer閳ユ獨 needs
- CW, 2Hz modulation output at 650nm, and CW, 270Hz,1KHz,2KHz modulation output at other wavelengths.
- High stability of the output power
- Stable output wavelength
- Backlight LCD display supports night operation
- Compact size and decent appearance
- Large LCD, easy operation
- Alternative 10 minutes Auto-off function conserving battery life
Specifications
Type | JW3109 | ||||
Wavelengths(nm) | 650 | 1310/1550 | 850/1300 | 850/1300/1310/1550 | |
Emitter Type | FP-LD,LED or others please specify | ||||
Typical Output Power (dBm) | 0 | -7dBm for LD, -20dBm for LED | |||
Spectral Width(nm) | 閿?0 | ||||
Output Stability | 鍗0.05dB/15mins; 鍗0.1dB/ 8hours | ||||
Modulation Frequencies | CW,2Hz | CW,270Hz,1KHz,2KHz | |||
Optical Connector | FC/ universal adaptor | FC/PC | |||
Power Supply | Alkaline Battery(3 AA 1.5V batteries) | ||||
Battery Operating Time(hour) | 45 | ||||
Operating Temperature(閿?/span>) | -10~+60 | ||||
Storage Temperature(閿?/span>) | -25~+70 | ||||
Dimension | 23.5*16*8cm | ||||
Weight | 0.6kg | ||||
Joinwit Recommendation | |||||
JW3109 Handheld Light Source is designed for optimal use with JW3208 Optical Power Meter for measuring optical loss on both single mode and multi mode fiber cable. | |||||
