Brand:YZ
Module name:Gigabit Media Converter
Model:PGE1000
鈻 Support 1000Base-FX optical fiber transmission standard
鈻 Thelongest transmission distance can reach 80Km
鈻 10/100/1000Mbps, ful duplex/half duplex auto negotiation
鈻 Support LFP(Link Failover) function
鈻 One-keyelectric port 10M mandatory speed limit
鈻 Support half-duplex back pressure control and full-duplex flow control
鈻 Support IEEE802.3 af/at standard
The Media Converterr can perform photoelectric conversion
between 10/100/1000Base-T and 1000Base-FX networks. The product
contains one 10/100/1000M electrical port and one 1000M optical port,
which can meet the needs of users of fast Ethernet working groups at
long distances, high speeds and high bandwidths, and achieve
transmission distances up to 100KM. The product design complies with
IEEE802.3,IEEE802.3u,IEEE802.3ab,10/100/100Base-TX,1000Base
FXstandards.The product supports POE power supply and LFP
Features
(link failover function),which is especia ly suitable for various broadband
data networks and reliability data required for telecommunications, cable
TV, railways, military, financial securities, customs, civil aviation,
shipping, power, water conservancy, oil fields, etc. Or the establishment
of an IP data transmission private network is the ideal equipment for
building broadband campus networks, cable TV and inteligent
broadband residential fiber-to-building and fiber-to-the-home.
between 10/100/1000Base-T and 1000Base-FX networks. The product
contains one 10/100/1000M electrical port and one 1000M optical port,
which can meet the needs of users of fast Ethernet working groups at
long distances, high speeds and high bandwidths, and achieve
transmission distances up to 100KM. The product design complies with
IEEE802.3,IEEE802.3u,IEEE802.3ab,10/100/100Base-TX,1000Base
FXstandards.The product supports POE power supply and LFP
Features
(link failover function),which is especia ly suitable for various broadband
data networks and reliability data required for telecommunications, cable
TV, railways, military, financial securities, customs, civil aviation,
shipping, power, water conservancy, oil fields, etc. Or the establishment
of an IP data transmission private network is the ideal equipment for
building broadband campus networks, cable TV and inteligent
broadband residential fiber-to-building and fiber-to-the-home.
Features
1 ×10/100/1000Base-T 1× 1000Base-FX
Support IEEE802.3af/at standard
One-key electric port 10M mandatory speed limit
Support 1000Base-FX optical fiber transmission standard
10/100/1000Mbps, ful duplex/half duplex auto negotiation
Support one key to turn on/off LFP (link failover)
Characteristics
Standard
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3z 1000Base-FX
IEEE 802.3af/at
Interfaces
Electrical port锛1x锛圧J45锛 10/100/1000Base-T
Optical port锛1x锛圫FP锛 1000Base-FX
Optical port characteristics
Rate锛100/1000Mbps
Wavelength锛single-mode 锛1310nm/1550nm ,Multimode锛850nm
Transmission distance锛歴ingle-mode锛2Km ,Multimode锛20/40/60/80Km
Interface type锛SFP
Electrical port characteristics
Rate锛10/100/1000Mbps
adaptive
Working mode锛ful duplex / half duple
Working mode锛ful duplex / half duple
Transmission distance锛0-~100m
Interface t e锛RJ45
LED
PWR, Link/Act FP, Link/Act TP, 1000M, SPD, POE
Power requirements
Input voltage: DC47~57V
SIze锛 94mmx70mmx26mm锛圠*W*H锛
Environmental restrictions
Operating temperature:-20 ~ 60°C (-4 ~ 140°F)
Storage temperature:-20 ~ 70°C (-4 ~ 158°F)
Relative humidity: 5 ~ 90% (non-condensing)
MTBF
Time : 500000 h
