Brand:HUAWEI
Module name:Flexible Card Broadband Service Unit
Model:BSUF-51,2 sub-slots
Flexible Card Broadband Service Unit(BSUF-51,2 sub-slots)
Description

OverviewTable 1 Basic information about the ME0DBSUF5170| Item | Details |
|---|
| Description | Flexible Card Broadband Service Unit(BSUF-51,2 sub-slots) | | Part Number | 03054629 | | Model | ME0DBSUF5170 | | Card type | Mother Flexible Board | | Silkscreen | BSUF-51 | Indicators and ButtonsTable 2 Indicators on the ME0DBSUF5170| Silkscreen | Name | Color | Status | Description |
|---|
| OFL | Offline indicator | Red | Steady on | The board can be removed. | | RUN | Running status indicator | Green | Fast blinking, twice every second (2 Hz) | The board is starting and has not completed registration. | | Green | Slow blinking, once every 2s (0.5 Hz) | The system is running properly. | Table 3 Buttons on the ME0DBSUF5170| Silkscreen | Name | Description |
|---|
| OFL | Board removal button | To remove a board, hold down the OFL button for about 6s until the OFL indicator turns on, and then remove the board. | Functions and FeaturesTable 4 Functions and features of the ME0DBSUF5170| Functions and Features | Description |
|---|
| Basic function | Supports 50G line-rate processing of broadband services. | | Reliability and availability | Hot swappable. | | Restrictions and remarks | - | | Breakout supported | No | | Interface rate auto-sensing supported | No | | Link protocol | - | Technical SpecificationsTable 5 Technical specifications of the ME0DBSUF5170| Item | Specification |
|---|
| Dimensions without packaging (H x W x D) [mm(in.)] | 40.1 mm x 399.2 mm x 535.6 mm (1.58 in. x 15.72 in. x 21.09 in.) | | Weight without packaging [kg(lb)] | 6.6 kg (14.55 lb) | | Typical power consumption [W] | 180 W | | Typical heat dissipation [BTU/hour] | 584 BTU/hour | | Long-term operating temperature [°C(°F)] | 0°C to 45°C (32°F to 113°F) | | Short-term operating temperature [°C(°F)] | –5°C to +55°C (23°F to 131°F) |
