ZTE_Enhanced SFUL_System Control And Switching Card

ZXA10 C600/C650 Enhanced System Control And Switching Card Type L

Switch
Control Card
Function
As the service data switching center and management and control center of the ZXA10 C600/C650/C620, the switch
control card provides the system control and management functions and implements non-blocking data switching between cards.
  • Enhanced SFUL / Enhanced SFUP / Enhanced SFUH / Enhanced SFUQ is the switch
    control card of ZXA10 C600/C650.
  • SPUF / SPUFS is the switch
    control card of ZXA10 C620.
The switch
control card supports the following functions:
  • Enhanced SFUL / Enhanced SFUP / Enhanced SFUH / Enhanced SFUQ provides one out-band management (MGMT) interface, one maintenance serial interface (Console), one USB interface, one mirroring diagnosis network interface (DIAG), and one line card debugging serial interface (ODB).
  • SPUF / SPUFS provides one out-of-band management (MGMT) interface, one maintenance serial interface (Console), one Environmental detection serial interface (Monitor, supporting 3 digital input interfaces and 1 digital output interface) and one line card debugging serial interface (ODB).
  • Enhanced SFUH / Enhanced SFUQ supports four 10GE/GE uplink interfaces.
  • SPUF / SPUFS provides four 10GE/GE Ethernet optical interfaces.
  • SPUFS supports the IEEE 1588 function.
  • Supports load balancing.
  • Hot swappable.

    C600_SFUL_1

    C600_SFUL_2

    C600_SFUL_3

    C600_SFUL_4

    C600_SFUL_5

    C600_SFUL_6
