ZTE_PRVR_ DC power interface card
Name: DC power interface card
Model: PRVR
Manufacturer: ZTE
Producing Area: CN
Simple Description: PRVR
Type-R DC power interface card
ZXA10 C600/C650
Price: Inquire   hot sale
The power card supports the following functions:
  • PRVR / PRVR(C) provides one –48V DC input interfaces to supply power to cards of the ZXA10 C600/C650. Each channel supports maximum 60A current.
  • PRSF provides one –48 V/–60 V DC input interfaces to supply power to cards of the ZXA10 C620, supports maximum 15A current.
  • PRAF supports 220 V/110 V AC input to supply power to cards of the ZXA10 C620, supports backup battery interface (including battery temperature sensor interface), and supports power input control switch.
  • PRVR / PRVR(C) supports hot swapping.
The ZXA10 C600/C650 supports two power cards. If the input voltages of the two power cards are the same, the two power cards operate in load sharing mode. ZXA10 C620 supports two DC power supply cards or one AC power supply card.
C600_PRVR_Power_1

C600_PRVR_Power_2

C600_PRVR_Power_3
