ZTE_ZXR10 5928E-FI-DC_Switch
Name: Switch
Model: ZXR10 5928E-FI-DC
Manufacturer: ZTE
Producing Area: CN
Simple Description: ZXR10 5928E-FI-DC 24port Switch include 1PCS DC Power, not include unlink
Price: Inquire   hot sale
ZXR10 5928E-FI-DC 24port Switch include 1PCS DC Power, not include unlink


Technical Specifcation
Fixed interfaces :24 GE SFP ports -
Expansion card:1*4 GE RJ45 ports/1*4 GE SFP ports/1*4 10GE SFP+ ports/1*2 10GE SFP+ ports
Backplane Capacity: 240Gbps
Switching Capacity : 128Gbps
Packet Forwarding Rate : 96Mpps
L2 Features:IEEE 802.1q VLAN,IEEE 802.1p,IEEE 802.3ad, STP,RSTP,MSTP, Selective QinQ, VLAN translation, PVLAN,DHCP Snooping,802.1x
L3 Features: Static routing, RIP, OSPF, ISIS, BGP,MCE
MPLS: LDP,MPLS TE,VPLS,VPWS,H-VPLS,MPLS L3 VPN,CE Dual-homing Protection
Reliability: LACP,ZESS,ZESR/ZESR+,VRRP,BFD
Clock synchronization: IEEE 1588v2, Synchronous Ethernet
Enhanced Features: MFF,M-BUTTON, EEE, Zero-Confguration
Dimensions(H*W*D):43.6*442*220mm
Maximum Weight: 4.8kg
Power supply(DC/AC): -48V; 100V~240V,50Hz~60Hz
Maximum power consumption:64W
Power redundancy pattern: Dual independent and swappable power supply modules
Heat dissipation: 180 BTU/h
Temperature, humidity: Working temperature:-5o C~+50oC ,humidity:10%~90%
MTBF/MTTR :> 200000 hours/ < 30 minutes
